- Computer installed;
- Flowmeter for pure water indication and one for waste/brine water indication;
- Stainless steel glycerin filled pressure gauges for front pressure and recycling pressure;
- Dry running protection sensors for tap water-in and between buffer tank and deck wash pump
- Pressure transmitter at deck wash pump out so deck wash pump stops when no water is asked
- RO main pressure pump for constantly good water flow and pressure over the membranes
- Deck wash pressure pump for approx. 8 bar pressure on the deck wash point. Comes with vortex flow meter to keep control over the water flow out of the buffer tank
- Quantity of pure water coming out of the water units 65% till 80%. Depending on water quality going in, flow rate and temperature of the water.
- Unit requires 230 Volt / 16 Ampere / 3000 Watt. (Can also be built in 400 Volt)
- Electra box with main power switch and unit on/off switch will be placed outside the unit LxWxH 380x380x210 and comes with 2 meter cable between E-box and unit. Cables come out at the back of the unit.
Aqua Force Compact 850
Article number: 60.00204- Produces ca. 850 L of pure water / hour
- Siemens Control 4” touch screen
- Frequency driven pressure pump
- Stainless steel frame 135x50x45 cm.
- Power 230 V / 2100 W – Ca. 145 kg
Additional Information
We also advise on this:
Front filter ART. 60.00008:
Water filter, combination with carbon and 5 micron filter. This filter has an easy change
bayonet connection and control manometers on water-inlet and water-outlet. Mainly to prevent the high chlorine content in the water
Water Softener ART. 60.00007 or 60.00012:
Baudoin Duplex Water Softener. Works fully automatic and rinses itself when the internal resin is saturated. Mainly to remove the hardness caused by calcium and magnesiumout of the water
